2. Installation and Wiring
Please refer to: Figure 1: Connection Diagram without Tamper per Zone and familiarise yourself with the
following sections.
*The kick start jumper must be in-circuit when using only a battery (i.e. no AC). Simply short
the pins out with a screwdriver, or use a jumper. Remove the short/jumper once the Panel
Status LED lights up (indicating power up), as leaving it on disables the low battery cut-out.*
Figure 1: Connection Diagram without Tamper per Zone
