An output can be assigned to a zone such that in the event of that zone causing an alarm condition, the
chosen output performs the selected option. A list of available actions and their corresponding values is
shown in Table 35.
Regardless of the action selected for a particular output, if it is programmed to clear on disarming of the
panel (locations 380-389), the output will revert to clear (set low) after any partition disarmed.
Each location represents a set of 8 zones:
Location 415 is zones 1-8
Location 416 is zones 9-16
Location 417 is zones 17-24
Location 418 is zones 25-32
Location 419 is zones 33-40
Location 420 is zones 41-48
Location 421 is zones 49-56
Location 422 is zones 57-64
Enter a 4-digit output and action for each of the 8 zones and program as 32-digit strings,
followed by the [*] key.
[INSTALLER CODE] [*] [4] [1] [5] [*] [ZONE NO.] [*] [OUTPUT] [ACTION] [*]
Refer to section 8.2 Programming Standard Locations to see how to scroll through data in a location
using the [*] key.
These locations allow you to configure the global programmable output events. Refer to Table 37 to view
the programmable output events per location.
LEDs 1-8 represent the output number, and LEDs 9-16 represent the action. Once a
programmable output has been enabled, the default action will be Pulse High [02].
If dual reporting is enabled, an output allocated to the dual reporting programmable output event
will be set when the panel dials the second phone number, and cleared when it hangs up at the
end of the transmission. This output follows the hook relay. It may be used to trigger switching
from the telephone line to a radio transmitter.
There is no output action for the fire sensor power and dual reporting programmable output
events.
