9.14 Reporting Codes - Advanced
This section describes how to configure custom reporting codes if the format of said reporting code is
not Contact ID o r SIA.
9.14.1 Global Reporting Codes
LOCATION 300
Global Reporting Code 1
This location is used to configure global reporting codes to be used in the event that neither Contact ID
nor SIA formats are used. These codes will be used for any of the other formats selected in section 9.5
Communications Setup - Advanced have been selected.
 Sub-location 1 is AC Fail
The Alarm Panel will transmit this code in the event of an AC failure but only after the AC
failure delay time has elapsed (location 15). Option 1 in Table 41 needs to be enabled.
 Sub-location 2 is AC Restore
The Alarm Panel will transmit this code once the AC restore delay time has elapsed
(location 15). It will however only be reported if an AC failure was registered. Option 4 in
Table 42 needs to be enabled.
 Sub-location 3 is Low Battery Monitor Fail
A low battery condition is reported when the battery voltage drops below 11V for a period
longer than 5 minutes or immediately if it drops below 10V. Option 5 in Table 41 needs to
be enabled.
 Sub-location 4 is Low Battery Monitor Restore
This code is reported once the battery voltage rises above 12V for a period of five
minutes. Option 8 in Table 42 needs to be enabled.
 Sub-location 5 is Auto Test
This code is reported at regular intervals (location 32). Option 8 in Table 43 needs to be
enabled.
 Sub-location 6 is Download
This code is reported once successful access to the panel has been obtained. Option 1
in Table 44 needs to be enabled.
 Sub-location 7 is Siren Monitor Fail
This code is reported when the siren fuse blows or when the siren or siren wiring is
tampered with. Option 4 in Table 41 needs to be enabled.
 Sub-location 8 is Aux 12V Monitor Fail
This code is reported when there is a problem with the Aux 12V. Option 6 in Table 41
needs to be enabled.
Enter a 2-digit reporting code for each of the 8 sub-locations and program as a 16-digit string,
followed by the [*] key.
[INSTALLER CODE] [*] [3] [0] [0] [*] [SUB-LOCATION] [*] [REPORTING CODE] [*]
The valid data range is: 01-FF, with 00 to disable.
If any of the sub-locations are disabled here, then the reporting codes will not report – even if they are
enabled at 9.16 Event Reporting Options - Advanced.
Refer to section 8.3.2 Using Sub-locations to see how to scroll from one sub-location to another using the
[*] key.
