NOTE:
Only an output can be entered for programmable output events 411-414.
Enter a 2-digit value for each partition and program as a 16-digit string, followed by the [*] key.
[INSTALLER CODE] [*] [LOCATION] [*] [PARTITION NO.] [*] [OUTPUT] [*]
Partition no. is: 1-8.
A NOTE ON ARM FOLLOW:
An output which has been set as an Arm Follow Programmable Output Event will mimic the ARM LED on
the keypad. The output will be set High when the partition is armed, set Low when the partition is
disarmed, and will flash when the partition has an alarm condition. The benefit of this is that you can
attach a siren, Remote Arm/Disarm LED Unit (862-84-10), etc to your Alarm Panel for an audible/visual
display of the panel‟s state.
Table 33 lists the addresses for the physical outputs and Table 34 lists the output actions.
Table 33: Output Address Physical Mapping Data
