This location is used to configure global reporting codes to be used in the event that Neither Contact ID
or SIA formats are used. These codes will be used when any of the other formats in section 9.5
Communications Setup - Advanced have been selected.
Sub-location 1 is Reserved
This sub-location is reserved.
Sub-location 2 is Bus-wired Peripheral Tamper
This code is reported when there is a tamper condition on any external device attached
to the keypad bus. Option 1 in Table 42 needs to be enabled.
Sub-location 3 is Bus-wired Peripheral Fail
This code is reported when any external device attached to the keypad bus goes
missing. Option 2 in Table 42 needs to be enabled.
Sub-location 4 is Box Tamper
This code is reported when the box tamper contacts are open for a period exceeding
200 ms. Option 8 in Table 41 needs to be enabled.
Sub-location 5 is Dedicated Panic
This code is reported when the dedicated panic zone is violated. Option 7 in Table 43
needs to be enabled.
Sub-location 6 is Reserved
This sub-location is reserved.
Sub-location 7 is Telephone Line Tamper
If telephone line monitoring is enabled (location 14), this code is reported if there is a
tamper on the telephone line. Option 3 in Table 41 needs to be enabled.
Sub-location 8 is Telephone Line Restore
If telephone line monitoring is enabled (location 14), this code is reported once the
telephone line integrity has been restored. Option 6 in Table 42 needs to be enabled.
Enter a 2-digit reporting code for each of the 8 sub-locations and program as a 16-digit string,
followed by the [*] key.
NOTE:
When programming using the string method, reserved sub-locations will still need data to be inputted
into them to maintain the 16-digits needed to successfully program. Inputting data into a reserved sub-
location will not affect the value of the sub-location. Reserved sub-locations have a value of 00.
[INSTALLER CODE] [*] [3] [0] [1] [*] [SUB-LOCATION] [*] [REPORTING CODE] [*]
The valid data range is: 01-FF, with 00 to disable.
If any of the sub-locations are disabled here, then the reporting codes will not report – even if they are
enabled at 9.16 Event Reporting Options - Advanced.
Refer to section 8.3.2 Using Sub-locations to see how to scroll from one sub-location to another using the
[*] key.
NOTE:
The values are hexadecimal. Refer to Table 3 on how to program hexadecimal values.
