LOCATIONS 581 - 588
Split Reporting Partitions 1-8
Table 45: Split Reporting Partitions 1-8 Data
LED
On/Off
Action
LED
On/Off
Reporting Pair
1
ON
Enable duress reporting
9
ON
Telephone module 2
OFF
Disable duress reporting
OFF
Telephone module 1
2
ON
Enable keypad panic
reporting
10
ON
Telephone module 2
OFF
Disable keypad panic
reporting
OFF
Telephone module 1
3
ON
Enable fire reporting
11
ON
Telephone module 2
OFF
Disable fire reporting
OFF
Telephone module 1
4
ON
Enable medical reporting
12
ON
Telephone module 2
OFF
Disable medical reporting
OFF
Telephone module 1
5
ON
Enable keypad lockout
reporting
13
ON
Telephone module 2
OFF
Disable keypad lockout
reporting
OFF
Telephone module 1
6
ON
Reserved
14
ON
Reserved
OFF
Reserved
OFF
Reserved
7
ON
Enable armed without user
code reporting
15
ON
Telephone module 2
OFF
Disable armed without user
code reporting
OFF
Telephone module 1
8
ON
Reserved
16
ON
Reserved
OFF
Reserved
OFF
Reserved
Default values are shaded
Each location represents a partition:
 Location 581 is partition 1
 Location 582 is partition 2
 Location 583 is partition 3
 Location 584 is partition 4
 Location 585 is partition 5
 Location 586 is partition 6
 Location 587 is partition 7
 Location 588 is partition 8
