IDS X64

Section: 9
IDS X64 Installer Manual 700-398-02D Issued August 2010
47
LOCATION 176
No Movement Medical Alarm End (default = 0100)
Program the end time to stop checking for movement. For example, using 06:00 programmed into
location 175 and if 2 hours is needed, then program 08:00.
Enter a 4-digit time [HHMM] for each of the 8 partitions and program as a 32-digit string,
followed by the [*] key.
[INSTALLER CODE] [*] [1] [7] [6] [*] [PARTITION NO.] [*] [HHMM] [*]
The valid data range: 00h00m – 23h59m.
Partition no. is: 1-8.
Refer to section 8.3.2 Using Sub-locations to see how to scroll from one sub-location to another using the
[*] key.
9.9 Auto Arm - Advanced
LOCATION 180
Auto Arm Time (default = 2400)
This location sets the time at which a particular partition will auto arm. To disable this location, enter 2400
as the time.
EXAMPLE:
To auto arm at 11:35 pm, enter 2335. All four digits must be entered, including any leading zeros (0100
for 1 am).
Enter a 4-digit time for each of the 8 partitions and program as a 32-digit string, followed by
the [*] key.
[INSTALLER CODE] [*] [1] [8] [0] [*] [PARTITION NO.] [*] [HHMM] [*]
The valid data range is: 00h00m – 23h59m, with 24h00m to disable.
Partition no. is: 1-8.
Refer to section 8.3.2 Using Sub-locations to see how to scroll from one sub-location to another using the
[*] key.
LOCATIONS 181 - 188
Auto Arm/Disarm Days (default = all OFF)
These bitmapped locations set the days on which the selected partition will auto arm and
disarm at the times programmed in locations 180 and 189 respectively. Refer to Table 23 for the data you
can input.
Each location represents a partition:
 Location 181 is partition 1
 Location 182 is partition 2
 Location 183 is partition 3
 Location 184 is partition 4
 Location 185 is partition 5
 Location 186 is partition 6
 Location 187 is partition 7
 Location 188 is partition 8
