IDS X64

Section: 9
IDS X64 Installer Manual 700-398-02D Issued August 2010
56
LOCATIONS 251 - 258
Keypad Options
These locations are used to configure options for a keypad. Refer to Table 27 for the available
options.
Each location represents a keypad:
 Location 251 is keypad 1
 Location 252 is keypad 2
 Location 253 is keypad 3
 Location 254 is keypad 4
 Location 255 is keypad 5
 Location 256 is keypad 6
 Location 257 is keypad 7
 Location 258 is keypad 8
(This is an advanced location).
Table 27: Keypad Options Data
LED
On / Off
Action
1
ON
The keypad will timeout back to its default partition
after it has been used to view another partition
OFF
The keypad will not timeout and will continue to show
current partition information
2
ON
Keypad sleep mode enabled
OFF
Keypad sleep mode disabled
3
ON
Enable Global Keypad Status
OFF
Disable Global Keypad Status
Default values are shaded
 LED 3 must be ON in order for LED 1 to have any effect.
 The Global Keypad Status will allow sixteen zones to be displayed regardless of the partition to
which either the keypad or zones are assigned.
On a LED keypad from the keypad start zone number plus 16 zones.
On a LCD keypad from the keypad start zone number up to 64 zones.
