Section: 9
IDS X64 Installer Manual 700-398-02D Issued August 2010
9.15.2 Partition Event Driven Outputs - Advanced
The following locations determine allow you to assign outputs and output actions to partition events for
each partition.
Partition Programmable Output Events
These locations allow you to configure various programmable output events per partition. See locations
423-426, “Global Programmable Output Events” for details on programming the programmable output
events.
Table 31 and Table 32 summarise the partition specific events that can be assigned to the outputs. Only
one output and action can be assigned per partition, unless otherwise stated.The maximum current
available from a programmable output is 25mA.
For zone and keypad events, any zone or keypad assigned to a particular partition being programmed
will trigger an output if that event occurs.
On an LED keypad, LEDs 1-8 represent the output number, and LEDs 9-16 represent the action.
Table 31: Partition Programmable Output Events for Locations 390-410
Close Programmable Output Event
Stay Close Programmable Output Event
Open Programmable Output Event
Cancel Programmable Output Event
Alarm Restoral Programmable Output Event
Bypass Programmable Output Event
Forced Arm Programmable Output Event
Zone Tamper Programmable Output Event
Zone Tamper Restoral Programmable Output Event
Zone Shutdown Programmable Output Event
Zone Shutdown Restoral Programmable Output Event
Keypad Panic Programmable Output Event
Keypad Fire Programmable Output Event
Keypad Medical Programmable Output Event
Keypad Lockout Programmable Output Event
Duress Programmable Output Event
Verifies Cross-zone Trigger Programmable Output Event
Burglary Programmable Output Event
Panic Programmable Output Event
Fire Programmable Output Event (Refer to zones 1-8)
Tamper Zone Programmable Output Event
Enter a 4-digit value (2 digits as per Table 33 and 2 digits as per Table 34) for each partition
and program as a 32-digit string, followed by the [*] key.
[INSTALLER CODE] [*] [LOCATION] [*] [PARTITION] [*] [OUTPUT] [ACTION] [*]
