8. Programming of the Panel
The X64 can be fully programmed using the X64 LED keypad; the system is optimised to use an LCD
keypad. The following section describes how programming data is represented in the X64 and how to
program it, specifically with the LED keypad.
For all programming procedures, the [*] key functions as the <ENTER> key and the [#] hash key
functions as a <CLEAR> or an <EXIT> program key.
Invalid data entries are indicated by means of an error beep consisting of 3 short beeps of the keypad
buzzer.
There are two location categories:
Standard locations which are single tiered and do not contain any sub-locations.
Extended locations, which are double tiered and have strings or sub-locations depending on the
installers programming preference.
Both standard and extended locations may contain further sub-categories referred to as bitmapped
locations.
For both main categories, clear visual keypad prompts are provided, which aid the programming
process.
NOTE:
When you use the [*] key to scroll through a bitmapped location, it will scroll through the pages.
When using the [*] key to scroll through numbered locations, it will scroll through the bytes.
Alpha-numeric locations (location 51 - telephone number), will show 1 digit per press of the [*]
key.
Numeric locations (location 197 – installers code), will show 2 digits per press of the [*] key.
To view how the data is represented, please see Table 1.
Below are various programming symbols you will see throughout the manual:
Indicates programming a standard location
Indicates programming using the string method
Indicates programming a sub-location
Indicates programming a location/sub-location with a bitmap
Where a hexadecimal number must be programmed, use the [MODE] key as per Table 3.
Table 3: Hexadecimal Values
