Section: 9
IDS X64 Installer Manual 700-398-02D Issued August 2010
If any of the sub-locations are disabled here, then the reporting codes will not report – even if they are
enabled at 9.16 Event Reporting Options - Advanced.
Partition no. is: 1-8.
Refer to section 8.3.2 Using Sub-locations to see how to scroll from one sub-location to another using the
[*] key.
NOTE:
The values are hexadecimal. Refer to Table 3 on how to program hexadecimal values.
Keypad Lockout Reporting Code
The 2-digit keypad lockout code is reported when a keypad lockout condition occurs on any keypad
belonging to the specified partition. Option 5 in Table 45 needs to be enabled.
Enter a 2-digit reporting code for each of the 8 partitions and program as a 16-digit string,
followed by the [*] key.
[INSTALLER CODE] [*] [3] [4] [0] [*] [PARTITION NO.] [*] [REPORTING CODE] [*]
The valid data range is: 01-FF, with 00 to disable.
If any of the sub-locations are disabled here, then the reporting codes will not report – even if they are
enabled at 9.16 Event Reporting Options - Advanced.
Partition no. is: 1-8.
Refer to section 8.3.2 Using Sub-locations to see how to scroll from one sub-location to another using the
[*] key.
NOTE:
The values are hexadecimal. Refer to Table 3 on how to program hexadecimal values.
9.14.4 User Reporting Codes
The 2-digit close code is reported when the panel is AWAY ARMED. This location is configured per user.
Refer to the User Manual where option 1 of User Reporting Codes Enabled, needs to be enabled.
Each location represents a set of 16 users:
Location 342 represents users 1-16
Location 343 represents users 17-32
Location 344 represents users 33-48
Location 345 represents users 49-64
Location 346 represents users 65-80
Location 347 represents users 81-96
Location 348 represents users 97-112
Location 349 represents users 113-128
Enter a 2-digit reporting code for each of the 16 users and program as a 32-digit string,
followed by the [*] key.
[INSTALLER CODE] [*] [LOCATION] [*] [USER] [*] [REPORTING CODE] [*]
The valid data range is: 01-FF, with 00 to disable.
