IDS X64

Section: 9
IDS X64 Installer Manual 700-398-02D Issued August 2010
75
The valid data range is: 00h00m – 23h59m, with 24h00m to disable.
Output no. is: 1-5.
LOCATION 439 - 444
Zone Expander Output ON Time (default = 2400)
Enter a 4-digit time, [HHMM], for each of the 6 zone expanders output and program as an 8-
digit string, followed by the [*] key.
[INSTALLER CODE] [*] [LOCATION] [*] [OUTPUT NO.] [*] [HHMM] [*]
The valid data range is: 00h00m – 23h59m, with 24h00m to disable.
Output no. is: 1-2.
Refer to section 8.3.2 Using Sub-locations to see how to scroll from one sub-location to another using the
[*] key.
LOCATION 447
Keypad Output ON Time (default = 2400)
Enter a 4-digit time, [HHMM], for each of the 8 keypads output and program as a 32-digit
string, followed by the [*] key.
[INSTALLER CODE] [*] [4] [4] [7] [*] [OUTPUT NO.] [*] [HHMM] [*]
The valid data range is: 00h00m – 23h59m, with 24h00m to disable.
Output no. is: 1-8.
9.15.6 Output Scheduling Off Time - Advanced
The following locations determine the programmed time for the programmable output to turn off. These
outputs can either be set high (on) or low (off). For the following locations to work the appropriate on/off
days (locations 458-498), must be selected.
LOCATION 448
Onboard Output OFF Time (default = 2400)
Enter a 4-digit time, [HHMM], for each of the 5 onboard outputs and program as a 20-digit
string, followed by the [*] key.
[INSTALLER CODE] [*] [4] [4] [8] [*] [OUTPUT NO.] [*] [HHMM] [*]
The valid data range is: 00h00m – 23h59m, with 24h00m to disable.
Output no. is: 1-5.
LOCATION 449 - 454
Zone Expander Output OFF Time (default = 2400)
Enter a 4-digit time, [HHMM], for each of the 6 zone expander outputs and program as an 8-
digit string, followed by the [*] key.
[INSTALLER CODE] [*] [LOCATION] [*] [OUTPUT NO.] [*] [HHMM] [*]
The valid data range is: 00h00m – 23h59m, with 24h00m to disable.
Output no. is: 1-2.
