IDS X64

Section: 9
IDS X64 Installer Manual 700-398-02D Issued August 2010
37
 If the system is armed using the quick stay key [5], the system will report a close by user 131.
 If the system is armed using the stay arm and go key [6], the system will report a close by user
132.
 If the system is armed by means of the auto arm function, the system will report a close by user
133.
 If the system is armed with the download software, the system will report a close by user 134.
 These user numbers are hard coded, and they are used when the above actions are reported to
a monitoring company.
 In order for these codes to be report, option 7 in Table 45 needs to be enabled.
NOTES ON CONTACT ID:
If the panel has been programmed to use Contact ID, it will not be necessary to program individual
reporting codes. Provision has been made to enable/disable the reporting of certain groups of codes.
Any event that relates to a specific zone, or to a specific user, will have the relevant zone/user number
appended to the end of the Contact ID reporting code.
LOCATION 41
Telephone Number 1 Communications Format (default = 5)
The value entered into this location selects the primary communication format. Select from
Table 18 the value that corresponds to the required format. During communication, the green LED on the
PCB will turn on indicating that the panel has taken the telephone off-hook. If programmed accordingly,
the keypad will beep after receiving a handshake from the base station. This indicates a successful
transmission of data. Refer to Table 18 for the available communication formats.
[INSTALLER CODE] [*] [4] [1] [*] [COMMUNICATIONS FORMAT] [*]
The valid data range is: 0 – 8.
NOTE:
Refer to section 9.16 Event Reporting Options - Advanced, to see how to enable split reporting.
Table 18: Communications Format Data
Value
Format Name
Description
0
Ademco Express
Dual Tone HS, DTMF
1
FBI 4 x 2 (With Parity)
1.8kHz TX, 2.3kHz HS, 40PPS
2
FBI 4 x 2 (No Parity)
1.8kHz TX, 2.3kHz HS, 20PPS
3
Silent Knight 4 x 2 Fast
1.9kHz TX, 1.4kHz, 20PPS
4
Silent Knight 4 x 2 Slow
1.9kHz TX, 1.4kHz, 20PPS
5
Contact ID
Dual Tone HS, DTMF
6
Reserved
7
SIA Reporting
Bell 103 FSK, HS
8
Reserved
TX = Transmit
HS = Handshake
PPS = Pulses per Second
LOCATION 42
Telephone Number 2 Communications Format (default = 5)
If dual reporting is enabled then this format will be used to report to phone number 2, which
belongs to reporting module 1. Refer to Table 18 for the available communication formats.
