Refer to section 8.3.2 Using Sub-locations to see how to scroll from one sub-location to another using the
[*] key.
NOTE:
The values are hexadecimal. Refer to Table 3 on how to program hexadecimal values.
The 2-digit zone swinger shutdown restore code is reported when a swinger shutdown zone is
automatically restored i.e. un-bypassed. Option 8 in Table 40 needs to be enabled.
Each location represents a set of 16 zones:
Location 332 is zones 1-16
Location 333 is zones 17-32
Location 334 is zones 33-48
Location 335 is zones 39-64
Enter a 2-digit reporting code for each of the 16 zones and program as a 32-digit string,
followed by the [*] key.
[INSTALLER CODE] [*] [LOCATION] [*] [ZONE NO.] [*] [REPORTING CODE] [*]
The valid data range is: 01-FF, with 00 to disable.
If any of the sub-locations are disabled here, then the reporting codes will not report – even if they are
enabled at 9.16 Event Reporting Options - Advanced.
Refer to section 8.3.2 Using Sub-locations to see how to scroll from one sub-location to another using the
[*] key.
NOTE:
The values are hexadecimal. Refer to Table 3 on how to program hexadecimal values.
9.14.3 Partition Reporting Codes
The 2-digit duress code is reported when a duress code is entered into any keypad belonging to the
specified partition. Option 1 in Table 45 needs to be enabled.
Enter a 2-digit reporting code for each of the 8 partitions and program as a 16-digit string,
followed by the [*] key.
[INSTALLER CODE] [*] [3] [3] [6] [*] [PARTITION NO.] [*] [REPORTING CODE] [*]
The valid data range is: 01-FF, with 00 to disable.
If any of the sub-locations are disabled here, then the reporting codes will not report – even if they are
enabled at 9.16 Event Reporting Options - Advanced.
Partition no. is: 1-8.
Refer to section 8.3.2 Using Sub-locations to see how to scroll from one sub-location to another using the
[*] key.
NOTE:
The values are hexadecimal. Refer to Table 3 on how to program hexadecimal values.
