Section: 9
IDS X64 Installer Manual 700-398-02D Issued August 2010
If any of the sub-locations are disabled here, then the reporting codes will not report – even if they are
enabled at 9.16 Event Reporting Options - Advanced.
Refer to section 8.3.2 Using Sub-locations to see how to scroll from one sub-location to another using the
[*] key.
NOTE:
The values are hexadecimal. Refer to Table 3 on how to program hexadecimal values.
Zone Force Arm Reporting Code
The 2-digit force zone arm code is transmitted if a partition is programmed to allow forced arming
(arming with a violated zone) and a zone is violated at the time of arming. Option 4 in Table 40 needs to
be enabled.
Each location represents a set of 16 zones:
Location 324 is zones 1-16
Location 325 is zones 17-32
Location 326 is zones 33-48
Location 327 is zones 39-64
Enter a 2-digit reporting code for each of the 16 zones and program as a 32-digit string,
followed by the [*] key.
[INSTALLER CODE] [*] [LOCATION] [*] [ZONE NO.] [*] [REPORTING CODE] [*]
The valid data range is: 01-FF, with 00 to disable.
If any of the sub-locations are disabled here, then the reporting codes will not report – even if they are
enabled at 9.16 Event Reporting Options - Advanced.
Refer to section 8.3.2 Using Sub-locations to see how to scroll from one sub-location to another using the
[*] key.
NOTE:
The values are hexadecimal. Refer to Table 3 on how to program hexadecimal values.
Zone Swinger Shutdown Reporting Code
The 2-digit swinger shutdown zone code is reported if the system is armed and a zone is automatically
bypassed as a result of multiple violations of that zone. Option 7in Table 40 needs to be enabled.
Each location represents a set of 16 zones:
Location 328 is zones 1-16
Location 329 is zones 17-32
Location 330 is zones 33-48
Location 331 is zones 39-64
Enter a 2-digit reporting code for each of the 16 zones and program as a 32-digit string,
followed by the [*] key.
[INSTALLER CODE] [*] [LOCATION] [*] [ZONE NO.] [*] [REPORTING CODE] [*]
The valid data range is: 01-FF, with 00 to disable.
If any of the sub-locations are disabled here, then the reporting codes will not report – even if they are
enabled at 9.16 Event Reporting Options - Advanced.
