[INSTALLER CODE] [*] [LOCATION] [*] [ZONE NO.] [*] [REPORTING CODE] [*]
The valid data range is: 01-FF, with 00 to disable.
If any of the sub-locations are disabled here, then the reporting codes will not report – even if they are
enabled at 9.16 Event Reporting Options - Advanced.
Refer to section 8.3.2 Using Sub-locations to see how to scroll from one sub-location to another using the
[*] key.
NOTE:
The values are hexadecimal. Refer to Table 3 on how to program hexadecimal values.
LOCATIONS 316 - 319
Zone Tamper Restore Reporting Code
The 2-digit tamper restore code is reported when a zone tamper has been cleared. Option 6 in Table 40
needs to be enabled.
Each location represents a set of 16 zones:
 Location 316 is zones 1-16
 Location 317 is zones 17-32
 Location 318 is zones 33-48
 Location 319 is zones 39-64
Enter a 2-digit reporting code for each of the 16 zones and program as a 32-digit string,
followed by the [*] key.
[INSTALLER CODE] [*] [LOCATION] [*] [ZONE NO.] [*] [REPORTING CODE] [*]
The valid data range is: 01-FF, with 00 to disable.
If any of the sub-locations are disabled here, then the reporting codes will not report – even if they are
enabled at 9.16 Event Reporting Options - Advanced.
Refer to section 8.3.2 Using Sub-locations to see how to scroll from one sub-location to another using the
[*] key.
NOTE:
The values are hexadecimal. Refer to Table 3 on how to program hexadecimal values.
LOCATIONS 320 - 323
Zone Bypass Reporting Code
The 2-digit zone bypass code is reported when a zone has been bypassed while the panel is armed.
Option 3 in Table 40 needs to be enabled.
Each location represents a set of 16 zones:
 Location 320 is zones 1-16
 Location 321 is zones 17-32
 Location 322 is zones 33-48
 Location 323 is zones 39-64
Enter a 2-digit reporting code for each of the 16 zones and program as a 32-digit string,
followed by the [*] key.
[INSTALLER CODE] [*] [LOCATION] [*] [ZONE NO.] [*] [REPORTING CODE] [*]
The valid data range is: 01-FF, with 00 to disable.
