IDS X64

Section: 9
IDS X64 Installer Manual 700-398-02D Issued August 2010
68
Regardless of which partition they are allocated to, disarming any partition will clear these outputs.
Table 28: Clear Programmable Onboard Outputs Data
LED
Disarm Clear Output
1
Output 1
2
Output 2
3
Output 3
4
Output 4
5
Output 5
LOCATIONS 381 - 386
Clear Programmable Zone Expander Outputs on Disarming
This bitmapped location allows the 2 outputs of the 6 zone expanders to be cleared (set low)
on disarming. The output(s) to be cleared will be displayed by zone number LEDs. The programmable
outputs will clear when ANY partition is disarmed. Refer to Table 29 to view which zone number LED
corresponds to which zone expander output.
Each location represents a zone expander:
 Location 381 represents zone expander 1
 Location 382 represents zone expander 2
 Location 383 represents zone expander 3
 Location 384 represents zone expander 4
 Location 385 represents zone expander 5
 Location 386 represents zone expander 6
Table 29: Clear Programmable Zone Expander Outputs Data
LED
Output
1
Output 1
2
Output 2
LOCATION 389
Clear Programmable Keypad Outputs on Disarming
This bitmapped location allows the single outputs of the 8 keypads to be cleared (set low) on
disarming. The output/s to be cleared will be displayed by zone number LEDs. The programmable
outputs will clear when ANY partition is disarmed. Refer to Table 30 to view which zone number LED
corresponds to which keypad output.
Table 30: Clear Programmable Keypad Outputs Data
LED
Output
1
Keypad 1
2
Keypad 2
3
Keypad 3
4
Keypad 4
5
Keypad 5
6
Keypad 6
7
Keypad 7
8
Keypad 8
