IDS X64

Section: 9
IDS X64 Installer Manual 700-398-02D Issued August 2010
78
9.16 Event Reporting Options - Advanced
The following locations from 501-588 enable disable the reporting of events programmed into locations
300-373. If a reporting code has been programmed, and the reporting of that code is not enabled here –
then the reporting code will not report.
LOCATIONS 501 – 564
Split Reporting Zones 1 - 64
Locations 501 (zone 1) – 564 (zone 64) represent a bitmap of 64 split reporting zone locations.
Table 40: Split Reporting Zones Bitmap Data
LED
On/Off
Action
LED
On/Off
Reporting Pair
1
ON
Enable zone alarm reporting
9
ON
Telephone module 2
OFF
Disable zone alarm reporting
OFF
Telephone module 1
2
ON
Enable zone alarm restore
reporting
10
ON
Telephone module 2
OFF
Disable zone alarm restore
reporting
OFF
Telephone module 1
3
ON
Enable zone bypass
reporting
11
ON
Telephone module 2
OFF
Disable zone bypass
reporting
OFF
Telephone module 1
4
ON
Enable zone force arm
reporting
12
ON
Telephone module 2
OFF
Disable zone force arm
reporting
OFF
Telephone module 1
5
ON
Enable zone tamper
reporting
13
ON
Telephone module 2
OFF
Disable zone tamper
reporting
OFF
Telephone module 1
6
ON
Enable zone tamper restore
reporting
14
ON
Telephone module 2
OFF
Disable zone tamper restore
reporting
OFF
Telephone module 1
7
ON
Enable zone swinger
shutdown reporting
15
ON
Telephone module 2
OFF
Disable zone swinger
shutdown reporting
OFF
Telephone module 1
8
ON
Enable zone swinger
shutdown restore reporting
16
ON
Telephone module 2
OFF
Disable zone swinger
shutdown restore reporting
OFF
Telephone module 1
Default values are shaded
NOTE:
See section 9.5 Communications Setup - Advanced.
