This location is used to configure global reporting codes to be used in the event that Neither Contact ID
or SIA formats are used. These codes will be used when any of the other formats in section 9.5
Communications Setup - Advanced have been selected.
Sub-location 1 is Wired Zone Expander Low Power Supply Monitoring
This code is reported when a wired zone expander experiences a low power supply.
Sub-location 2 is Wired Zone Expander Low Power Supply Restore
This code is reported when a wired zone expander recovers from a low power supply.
Sub-location 3 is Reserved
This sub-location is reserved.
Sub-location 4 is Reserved
This sub-location is reserved.
Sub-location 5 is Reserved
This sub-location is reserved.
Sub-location 6 is Reserved
This sub-location is reserved.
Sub-location 7 is Reserved
This sub-location is reserved.
Sub-location 8 is Reserved
This sub-location is reserved.
Enter a 2-digit reporting code for each of the 8 sub-locations and program as a 16-digit string,
followed by the [*] key.
NOTE:
When programming using the string method, reserved sub-locations will still need data to be inputted
into them to maintain the 16-digits needed to successfully program. Inputting data into a reserved sub-
location will not affect the value of the sub-location. Reserved sub-locations have a value of 00.
[INSTALLER CODE] [*] [3] [0] [3] [*] [SUB-LOCATION] [*] [REPORTING CODE] [*]
The valid data range is: 01-FF, with 00 to disable.
If any of the sub-locations are disabled here, then the reporting codes will not report – even if they are
enabled at 9.16 Event Reporting Options - Advanced.
Refer to section 8.3.2 Using Sub-locations to see how to scroll from one sub-location to another using the
[*] key.
NOTE:
The values are hexadecimal. Refer to Table 3 on how to program hexadecimal values.
9.14.2 Zone Reporting Codes
The 2-digit zone alarm code is reported when the zone is violated during an arm cycle or if a Panic or 24-
Hour zone is violated. Option 1 in Table 40 needs to be enabled.
Each location represents a set of 16 zones:
Location 304 is zones 1-16
Location 305 is zones 17-32
Location 306 is zones 33-48
Location 307 is zones 39-64
