These locations allow you to program the zone types for zones 1-64.The zones are divided into 8 zones
per location. After the zone type is programmed for zones 9 through 64, they will need to be assigned to
a partition before being enabled.
Refer to section 9.11 Partition Options to see how to add zones to partitions and what options are
available.
Each location represents a set of 8 zones:
Location 1 is zones 1-8
Location 2 is zones 9-16
Location 3 is zones 17-24
Location 4 is zones 25-32
Location 5 is zones 33-40
Location 6 is zones 41-48
Location 7 is zones 49-56
Location 8 is zones 57-64
Refer to Table 5 for available zone types.
NOTE:
If you require a panic zone whose status can be viewed on a keypad, use a panic on zones 1-64
by programming 03 into the zone. Do NOT use the dedicated panic for this purpose, as it cannot
be viewed on a keypad.
Zones 1-8 are onboard zones.
Zones 9-16 are plug-in expander zones.
Zones 17-64 are expander zones.
