IDS X64

Section: 9
IDS X64 Installer Manual 700-398-02D Issued August 2010
26
Table 6: Zone Types in String Format
Zones
Loc
Sub-loc
As Strings
Zone Type
1 - 8
1
n/a
0102040404040404
ref above table
9 - 16
2
n/a
0000000000000000
All Disabled
17 - 24
3
n/a
0000000000000000
All Disabled
25 - 32
4
n/a
0000000000000000
All Disabled
33 - 40
5
n/a
0000000000000000
All Disabled
41 - 48
6
n/a
0000000000000000
All Disabled
49 - 56
7
n/a
0000000000000000
All Disabled
57 - 64
8
n/a
0000000000000000
All Disabled
Table 7: Zone Types in Sub-location Format
Zone
Loc
Sub-Loc
As Sub-locations
Zone Type
1
1
1
01
Entry / Exit
2
1
2
02
Follower
3
1
3
04
Audible Instant
4
1
4
04
Audible Instant
5
1
5
04
Audible Instant
6
1
6
04
Audible Instant
7
1
7
04
Audible Instant
8
1
8
04
Audible Instant
The valid data range is: 00 – 05, 08, 10 – 15.
9.2 Global Setup
LOCATION 10
Zone Shutdown Count (default = 5)
This location determines the number of times a zone may be violated while the panel is armed
before it is automatically bypassed. Disarming the panel will clear all bypassed zones.
The Zone Shutdown Count set here applies to all zones that have option 3 (shutdown zone) enabled in
locations 101-164.
[INSTALLER CODE] [*] [1] [0] [*] [ZONE SHUTDOWN COUNT] [*]
The valid data range is: 1 – 15.
LOCATION 11
Programmable Zone Loop Response Time (default = 2)
The zone loop response time is the period of time for which a zone must remain violated before
a violation is registered. The time is calculated in 12 millisecond increments starting at 12ms. A partial
table between the values of 1 and 255 is shown in Table 8; times not shown on the table can be
calculated as per the following example:
198 x 0.012 = 2.38 seconds.
(This is an advanced location).
To program the time into this location, the format is [MMSS].
[INSTALLER CODE] [*] [1] [1] [*] [ZONE LOOP RESPONSE TIME] [*]
