2.1.5 Key-Switch or Remote Control Unit
A key-switch or non-IDS remote receiver may be connected to any zone to allow remote arm/disarm and
remote panic capability.
When using a key-switch or remote control unit, a 3K3 resistor must be connected between the
zone input and ground.
Use only a spring-loaded momentary key-switch or non-latching remote control unit.
2.2 Installing a Zone Expander Module
When installing a zone expander module refer to the document supplied with the module. Note that up to
6 bus-wired, 8-zone expander modules (P/N: 860-06-X-08S) and 1 plug-in expander (P/N: 860-06-X-08PI)
may be added to the IDS X64 Alarm Panel. Zones 9-16 are reserved for the Plug-in Zone Expander
module.
2.3 IDS Remote Receiver
Up to 4 IDS Remote Receivers (P/N: 860-07-X02-DI) may be connected to the keypad Bus. Using this
facility allows remote arming and disarming of the panel while providing user identification for a maximum
of 128 remotes.
For a full list of features and benefits of the receiver, please see the manual that comes with it.
2.4 Radio Transmitter Connection
When connecting a radio transmitter, use the TX terminal provided on the panel to supply power to the
transmitter. This output is protected by a 4 Amp fuse.
3. Hardware Default Switch
Use the hardware default switch (refer to Figure 1) to return the panel to its factory default settings.
The procedure to default the panel is as follows:
1. Remove the battery and AC power from the panel
2. If you are only using a battery make sure that the kick-start jumper is in circuit
3. Hold down the default switch and reapply power to the panel (battery or AC)
4. Wait for the Panel Status LED to flash
5. Release the default switch
6. Remove the kick-start jumper, if one was used
7. Defaulting is complete once the Panel Status LED starts flashing
The effects of applying the default:
1. Factory default values are restored to all locations
2. All attached keypad IDs are defaulted
3. The event log is not defaulted
4. The “system default” event is logged to the event log
NOTE:
The hardware default switch can be disabled in location 35.
See also: Defaulting the Panel or Master User Code – location 0.
