Section: 9
IDS X64 Installer Manual 700-398-02D Issued August 2010
[INSTALLER CODE] [*] [2] [4] [0] [*] [KEYPAD NO.] [*] [PARTITION NO.] [*]
The valid data range is: 1 – 8.
Partition no. is: 1-8.
Refer to section 8.3.2 Using Sub-locations to see how to scroll from one sub-location to another using the
[*] key.
Keypad Display Start Zone (default = Zone 1)
The zones which a particular LED keypad displays is determined by programming the keypad start zone
location. The number programmed into this location is the zone which will be assigned to LED 1 on the
keypad. The keypad will display subsequent zones in order. The keypad will only display zones
belonging to its partition.
Enter a 2-digit display start zone (01 – 64) for each of the 8 keypads and program as a 16-
digit string, followed by the [*] key.
[INSTALLER CODE] [*] [2] [4] [1] [*] [KEYPAD NO.] [*] [START ZONE] [*]
The valid data range is: 01 – 64.
Refer to section 8.3.2 Using Sub-locations to see how to scroll from one sub-location to another using the
[*] key.
NOTE:
This only applies to LED keypads and not LCD keypads.
Keypad Zone Number (default = 0 i.e. Disabled)
A keypad zone must be allocated to any zone number (1 – 64), before it can be used. The corresponding
zone type must be programmed in locations 1 – 8 and the properties configured in locations 101 – 164. If
you configure a keypad to a zone number that is already a wired zone, then the keypad will take priority
on the zone number.
Enter a 2-digit zone number (01 – 64) for each of the 8 keypads and program as a 16-digit
string, followed by the [*] key.
[INSTALLER CODE] [*] [2] [4] [2] [*] [KEYPAD NO.] [*] [ZONE NO.] [*]
The valid data range: 01 – 64.
Refer to section 8.3.2 Using Sub-locations to see how to scroll from one sub-location to another using the
[*] key.
View the data in this location to determine the Keypad ID (1 – 8).
[INSTALLER CODE] [*] [2] [4] [3] [*]
NOTE:
This is a read-only location and no data no can be changed.
