HD2 Series Inverter Function Parameter List
-135-
interface only with the correct user password. For the factory parameters, you need to enter
the correct factory password to enter the interface. (You are not advised to modify the factory
parameters. Incorrect parameter setting may cause operation exceptions or even damage to
the inverter.) If password protection is not in locked state, you can change the password any
time. You can set P07.00 to 0 to cancel the user password. When P07.00 is set to a non-zero
value during power-on, parameters are prevented from being modified by using the user
password function. When you modify function parameters through serial communication, the
user password protection function is also applicable and compliant with the same rule.
P00––Basic functions
0: Sensorless vector control (SVC) mode 0
1: SVC 1
2: Space voltage vector control mode
3: FVC
Note: To select 0, 1, or 3 as the control mode,
enable the inverter to perform motor parameter
autotuning first
Channel of
running
commands
0: Keypad
1: Terminal
2: Communication
Communication
mode of running
commands
0: Modbus/Modbus TCP
1: PROFIBUS/CANopen/DeviceNet
2: Ethernet
3: EtherCAT/PROFINET/EtherNet IP
4: Programmable card
5: Wireless communication card
6: Reserved
Note: 1, 2, 3, 4 and 5 are extended functions
which are applicable with corresponding cards.
Used to set the maximum output frequency of the
inverter. It is the basis of frequency setup and the
acceleration/deceleration.
Setting range: Max. (P00.04, 10.00)–630.00Hz
Upper limit of
running
frequency
Used to set the upper limit of inverter output
frequency. This value cannot be more than the
maximum output frequency.
When the set frequency is higher than the upper
limit, the inverter runs at the upper limit frequency.
Setting range: P00.05–P00.03 (Max. output
