Appendix A Expansion Cards
A.1 Model definition
The following table describes extension cards that supported by HD2. The extension cards are
optional.
Name
Model
Specification
IO extension card
HD2-E-IO
 4 digital inputs
 1 digital output
 1 analog input
 1 analog output
2 relay outputs: 1 double-contact output, and
1 single-contact output
IO expansion card 2
HD2-E-IO2
 4 digital inputs
 1 PT100
 1 PT1000
 2 relay outputs: single-contact output
Programmable extension
card
HD2-E-PLC
 Adopting the global mainstream
development environment PLC,
supporting multiple types of
programming languages, such
as the instruction language,
structural text, function block
diagram, ladder diagram,
continuous function chart, and
sequential function chart
 Supporting breakpoint commissioning
 Providing user program storage
space of 128 kB, and data
storage space of 64 kB
 6 digital inputs
 2 digital outputs
2 relay outputs: 1 double-contact output, and
1 single-contact output
Bluetooth communication
card
HD2-E-BTP
HD2-E-BTM
 Supporting Bluetooth 4.0
 With IMO’s mobile phone APP, you
can set the parameters and monitor
the states of the inverter through
Bluetooth
 The maximum communication distance
in open environments is 30 m.
 HD2-E-BTP is equipped with
a built-in antenna and
applicable to molded case
machines.
 HD2-E-BTM is configured with an
external sucker antenna and
