HD2 Series Inverter Basic Operation Guidelines
-92-
Function
code
Name
Description
Default
value
output frequency)
25: Ramp reference frequency (bipolar,
0–Max. output frequency)
26: Rotational speed (bipolar, 0–Speed
corresponding to max. output
frequency)
27: Value 2 set through
EtherCAT/PROFINET/EtherNet IP
communication (0–1000)
28: AO1 from the programmable card
(0–1000)
29: AO2 from the programmable card
(0–1000)
30: Rotational speed (0–Twice the
motor rated synchronous speed)
31: Output torque (Actual value, 0–
Twice the motor rated torque)
32: AI/AO temperature detection output
P06.17
Lower limit of AO1 output
-300.0%–P06.19
0.0%
P06.18
Corresponding AO1 output of
lower limit
0.00V–10.00V
0.00V
P06.19
Upper limit of AO1 output
P06.17–300.0%
100.0%
P06.20
Corresponding AO1 output of
upper limit
0.00V–10.00V
10.00V
P06.21
AO1 output filter time
0.000s–10.000s
0.000s
P06.22–
P06.26
Reserved variable
0–65535
0
P06.27
Lower limit of HDO output
-300.0%–P06.29
0.0%
P06.28
Corresponding HDO output of
lower limit
0.00–50.00kHz
0.0kHz
P06.29
Upper limit of HDO output
P06.27–300.0%
100.0%
P06.30
Corresponding HDO output of
upper limit
0.00–50.00kHz
50.00kHz
P06.31
HDO output filter time
0.000s–10.000s
0.000s
5.5.11 Digital input
The inverter carries four programmable digital input terminals and two HDI input terminals. The
function of all the digital input terminals can be programmed by function codes. HDI input terminal can
