IMO HD2-3.7A-43 - P22-Spindle Positioning

HD2 Series Inverter Function Parameter List
-246-
Function
code
Name
Description
Default
value
Modify
superposing)
When pulses are superposed, the output terminal
operates. After pulses are superposed, the
terminal does not operate.
P21.29
Speed
feedforward filter
time constant
(pulse string
speed mode)
It is the filter time constant detected by pulse string
when the speed reference source is set to pulse
string (P0.06=12 or P0.07=12).
Setting range: 0–3200.0ms
10.0ms
○
P21.30
Numerator of the
2nd command
ratio
1–65535
1000
○
P21.31
Pulse reference
speed measuring
method
0–2
0: Main control board
1: PG card
2: Hybrid
0
○
P21.32
Pulse reference
feedforward
source
0x0–0x1
0x0
◎
P21.33
Set value of
clearing encoder
count
0–65535
0
◎
P22––Spindle positioning
Function
code
Name
Description
Default
value
Modify
P22.00
Spindle
positioning mode
selection
Bit0: Enable spindle positioning
0: Disable
1: Enable
Bit1: Select spindle positioning reference point
0: Z pulse input
1: S2/S3/S4 terminal input
Bit2: Search for reference point
0: Search the reference point only once
1: Search the reference point every time
Bit3: Enable reference point calibration
0: Disable
1: Enable
Bit4: Positioning mode selection 1
0
○
