HD2 Series Inverter Function Parameter List
-220-
Function
code
Name
Description
Default
value
Modify
26: IMO extended speed and torque control output
27: IMO extended speed and torque control output
P15.38
Status
change/cycle
input instance
6977
69: IMO inverter input
70: ODVA basic speed control input
71: ODVA extended speed control input
72: ODVA speed and torque control input
73: ODVA extended speed and torque control
input
74: IMO basic speed control input
75: IMO extended speed control input
76: IMO extended speed and torque control input
77: IMO extended speed and torque control input
69
P15.39
Component 19
output length
8–32
32
P15.40
Component 19
input length
8–32
32
P15.41
BACnet
communication
method
(Reserved)
01
0: P16.22 is valid.
1: P15.42 is valid.
0
P15.42
BACnet_MSTP
baud rate
(Reserved)
0–5
0
P15.43
Communication
control word
expression
format
01
0: Decimal format
1: Binary format
0
P16––Functions of communication expansion card 2
Function
code
Name
Description
Default
value
Modify
P16.00
Reserved 0–0
0
P16.01
Reserved 0–0
0
P16.02
Ethernet
monitoring card
IP address 1
0–255
192
P16.03
Ethernet
monitoring card
0–255
168
