HD2 Series Inverter Basic Operation Guidelines
-49-
5.5.2 Common commissioning procedures
The common operation procedures are shown below (taking motor 1 as an example).
Start
Power on after confirming the
wiring is correct
Restore to default settings
Set the motor parameters of
P02.01–P02.05 as per the
motor nameplate
Set the motor parameters of
P02.15–P02.19 as per the
motor nameplate
Press QUICK/JOG to jog
If the motor rotates in an incorrect direction,
power off and exchange the motor wires of any
two phases, and power on again
Set the autotuning mode
Complete parameter rotary
autotuning
Partial parameter rotary
autotuning
Start autotuning by pressing
RUN, and stop after
autotuning is done
Set running frequency
Set speed running control
mode (P00.00)
SVC 1 (P00.00=0) SVC 2 (P00.00=1)
Space voltage vector control
mode (P00.00=2)
Set vector control parameters
in P03 group
Set vector control parameters
in P03 group
Set V/F parameters in P04
group
Set start/stop control
parameters in P01 group
Run after the run command is
given
Stop after the stop command
is given
End
Set running command channel
(P00.01, P00.02)
Complete parameter static
autotuning
Asynchronous
motor
Synchronous
motor
Note: If a fault occurs, find out the fault cause according to chapter 7 Troubleshooting.
The running command channel can be set by terminal commands besides P00.01 and P00.02.
