IMO HD2-3.7A-43 - P17-Status Viewing

HD2 Series Inverter Function Parameter List
-227-
Function
code
Name
Description
Default
value
Modify
communication
card gateway 3
P16.69
Industrial
Ethernet
communication
card gateway 4
0–255
1
◎
P17––Status viewing
Function
code
Name
Description
Default
value
Modify
P17.00
Set frequency
Display current set frequency of the inverter.
Range: 0.00Hz–P00.03
50.00Hz
●
P17.01
Output frequency
Display current output frequency of the inverter.
Range: 0.00Hz–P00.03
0.00Hz
●
P17.02
Ramp reference
frequency
Display current Ramp reference frequency of the
inverter.
Range: 0.00Hz–P00.03
0.00Hz
●
P17.03
Output voltage
Display current output voltage of the inverter.
Range: 0–1200V
0V
●
P17.04
Output current
Display the valid value of current output current of
the inverter.
Range: 0.0–5000.0A
0.0A
●
P17.05
Motor speed
Display current motor speed.
Range: 0–65535RPM
0 RPM
●
P17.06
Torque current
Display current torque current of the inverter.
Range: -3000.0–3000.0A
0.0A
●
P17.07
Exciting current
Display current exciting current of the inverter.
Range: -3000.0–3000.0A
0.0A
●
P17.08
Motor power
Display current motor power; 100% relative to
rated motor power, positive value is motoring
state, negative value is generating state.
Range: -300.0–300.0% (relative to rated motor
power)
0.0%
●
P17.09
Motor output
torque
Display current output torque of the inverter; 100%
relative to rated motor torque, during forward
running, positive value is motoring state, negative
value is generating state, during reverse running,
positive value is generating state, negative value is
motoring state.
Range: -250.0–250.0%
0.0%
●
P17.10
Estimated motor
The estimated motor rotor frequency under
0.00Hz
●
