Function
code
Name
Description
Default
value
1: Torque current reference
Tens place: Reserved
0: Reserved
1: Reserved
Hundreds place: Whether to enable ASR
integral separation
0: Disable
1: Enable
Thousands place: Reserved
0: Reserved
1: Reserved
P03.36
ASR differential gain
0.00–10.00s
0.00s
P03.37
High-frequency ACR
proportional coefficient
In the FVC (P00.00=3), when the
frequency is lower than the ACR
high-frequency switching threshold
(P03.39), the ACR PI parameters are
P03.09 and P03.10; and when the
frequency is higher than the ACR
high-frequency switching threshold
(P03.39), the ACR PI parameters are
P03.37 and P03.38.
Setting range of P03.37: 0–65535
Setting range of P03.38: 0–65535
Setting range of P03.39: 0.0–100.0% (in
relative to the maximum frequency)
1000
P03.38
High-frequency ACR
integral coefficient
1000
P03.39
ACR high frequency
switching threshold
100.0%
P17.32
Flux linkage
0.0–200.0%
0.0%
5.5.4 SVPWM control mode
The inverter also carries built-in SVPWM control function. SVPWM mode can be used in cases where
mediocre control precision is enough. In cases where an inverter needs to drive multiple motors, it is
also recommended to adopt SVPWM control mode.
The inverter provides multiple kinds of V/F curve modes to meet different field needs. You can select
corresponding V/F curve or set the V/F curve as needed.
Suggestions:
⚫ For the load featuring constant moment, such as conveyor belt which runs in straight line, as
the moment should be constant during the whole running process, it is recommended to adopt
straight-type V/F curve.
⚫ For the load featuring decreasing moment, such as fan and water pump, as the relation
between its actual torque and speed is squared or cubed, it is recommended to adopt the V/F
