HD2 Series Inverter Basic Operation Guidelines
-56-
Function
code
Name
Description
Default
value
P03.17
REV rotation frequency
upper limit set through
keypad in torque control
50.00Hz
P03.18
Setting source of
electromotive torque upper
limit
0: Keypad (P03.20)
1: AI1
2: AI2
3: AI3
4: Pulse frequency HDIA
5: Modbus/Modbus TCP communication
6: PROFIBUS/CANopen/DeviceNet
communication
7: Ethernet communication
8: Pulse frequency HDIB
9: EtherCAT/PROFINET/EtherNet IP
communication
10: Programmable card
11: Reserved
Note: For these settings, 100%
corresponds to the motor rated current.
0
P03.19
Setting source of braking
torque upper limit
0: Keypad (P03.21)
1–10: Same as those for P03.18
0
P03.20
Electromotive torque upper
limit set through keypad
0.0–300.0% (of the motor rated current)
180.0%
P03.21
Braking torque upper limit
set through keypad
180.0%
P03.22
Flux-weakening coefficient
in constant power area
0.1–2.0
0.3
P03.23
Min. flux-weakening point
in constant power area
10%–100%
20%
P03.24
Max. voltage limit
0.0–120.0%
100.0%
P03.25
Pre-exciting time
0.000–10.000s
0.300s
P03.32
Enabling torque control
0: Disable
1: Enable
0
P03.33
Flux weakening integral
gain
0–8000
1200
P03.35
Control optimization setting
0x0000–0x1111
Ones place: Torque command selection
0: Torque reference
0x0000
