HD2 Series Inverter Function Parameter List
-206-
Function
code
Name
Description
Default
value
Modify
runs except when the inverter has been damaged.
When fire mode 2 is selected, the inverter always
runs, but the inverter stops when encountering
OUT1, OUT2, OUT3, OC1, OC2, OC3, OV1, OV2,
OV3, or SPO.
Note: Terminal control must be used for a fire
mode.
When the fire mode has lasted 5 minutes, it is
reset, and no warranty of repair is processed.
P11.54
Running
frequency in fire
mode
0.00Hz–P00.03 (Max. output frequency)
50.00Hz
○
P11.55
Fire mode flag
0–1
Note: When the fire mode has lasted 5 minutes, it
is reset, and no warranty of repair is processed.
0
●
P11.56–
P11.69
rReserved
/
/
/
P12––Parameters of motor 2
Function
code
Name
Description
Default
value
Modify
P12.00
Type of motor 2
0: Asynchronous motor
1: Synchronous motor
0
◎
P12.01
Rated power of
asynchronous
motor 2
0.1–3000.0kW
Depends
on model
◎
P12.02
Rated frequency
of asynchronous
motor 2
0.01Hz–P00.03 (Max. output frequency)
50.00Hz
◎
P12.03
Rated speed of
asynchronous
motor 2
1–60000rpm
Depends
on model
◎
P12.04
Rated voltage of
asynchronous
motor 2
0–1200V
Depends
on model
◎
P12.05
Rated current of
asynchronous
motor 2
0.8–6000.0A
Depends
on model
◎
P12.06
Stator resistance
0.001–65.535Ω
Depends
○
