HD2 Series Inverter Basic Operation Guidelines
-111-
Function
code
Name
Description
Default
value
P10.10
Multi-step speed 4
-300.0–300.0%
0.0%
P10.11
Running time of step 4
0.0–6553.5s (min)
0.0s
P10.12
Multi-step speed 5
-300.0–300.0%
0.0%
P10.13
Running time of step 5
0.0–6553.5s (min)
0.0s
P10.14
Multi-step speed 6
-300.0–300.0%
0.0%
P10.15
Running time of step 6
0.0–6553.5s (min)
0.0s
P10.16
Multi-step speed 7
-300.0–300.0%
0.0%
P10.17
Running time of step 7
0.0–6553.5s (min)
0.0s
P10.18
Multi-step speed 8
-300.0–300.0%
0.0%
P10.19
Running time of step 8
0.0–6553.5s (min)
0.0s
P10.20
Multi-step speed 9
-300.0–300.0%
0.0%
P10.21
Running time of step 9
0.0–6553.5s (min)
0.0s
P10.22
Multi-step speed 10
-300.0–300.0%
0.0%
P10.23
Running time of step 10
0.0–6553.5s (min)
0.0s
P10.24
Multi-step speed 11
-300.0–300.0%
0.0%
P10.25
Running time of step 11
0.0–6553.5s (min)
0.0s
P10.26
Multi-step speed 12
-300.0–300.0%
0.0%
P10.27
Running time of step 12
0.0–6553.5s (min)
0.0s
P10.28
Multi-step speed 13
-300.0–300.0%
0.0%
P10.29
Running time of step 13
0.0–6553.5s (min)
0.0s
P10.30
Multi-step speed 14
-300.0–300.0%
0.0%
P10.31
Running time of step 14
0.0–6553.5s (min)
0.0s
P10.32
Multi-step speed 15
-300.0–300.0%
0.0%
P10.33
Running time of step 15
0.0–6553.5s (min)
0.0s
P10.34
Acceleration/decoration
time of steps 0–7 of simple
PLC
0x0000–0XFFFF
0000
P10.35
Acceleration/decoration
time of steps 8–15 of simple
PLC
0x0000–0XFFFF
0000
P17.27
Acutal stage of simple PLC
Displays the present stage of the simple
PLC function.
0
5.5.15 PID control
PID control, a common mode for process control, is mainly used to adjust the inverter output
frequency or output voltage by performing scale-division, integral and differential operations on the
difference between feedback signal of controlled variables and signal of the target, thus forming a
negative feedback system to keep the controlled variables above the target. It is applicable to flow
control, pressure control, temperature control, and so on. The following is the basic schematic block
