HD2 Series Inverter Function Parameter List
-145-
Function
code
Name
Description
Default
value
Modify
P01.09–P01.12).
Setting range of P01.29: 0.0–150.0% (of the rated
inverter output current)
Setting range of P01.30: 0.0–50.0s
Setting range of P01.31: 0.0–50.0s
P01.32
Pre-exciting time
of jogging
0–10.000s
0.000s
○
P01.33
Starting
frequency of
braking for
jogging to stop
0–P00.03
0.00Hz
○
P01.34
Delay to enter
sleep
0–3600.0s
0.0s
○
P02––Parameters of motor 1
Function
code
Name
Description
Default
value
Modify
P02.00
Type of motor 1
0: Asynchronous motor
1: Synchronous motor
0
◎
P02.01
Rated power of
asynchronous
motor 1
0.1–3000.0kW
Depends
on model
◎
P02.02
Rated frequency
of asynchronous
motor 1
0.01Hz–P00.03 (Max. output frequency)
50.00Hz
◎
P02.03
Rated speed of
asynchronous
motor 1
1–60000rpm
Depends
on model
◎
P02.04
Rated voltage of
asynchronous
motor 1
0–1200V
Depends
on model
◎
P02.05
Rated current of
asynchronous
motor 1
0.8–6000.0A
Depends
on model
◎
P02.06
Stator resistance
of asynchronous
motor 1
0.001–65.535Ω
Depends
on model
○
P02.07
Rotor resistance
of asynchronous
0.001–65.535Ω
Depends
on model
○
