HD2 Series Inverter Product Overview
-12-
Note:
⚫ The preceding nameplate is a standard product nameplate example. The marking such as CE,
TUV, and IP20 on the nameplate is marked according to the actual certificate result.
⚫ You can scan the QR code on the nameplate to download the product App and manual.
3.5 Type designation key
The type designation key contains product information. You can find the type designation key on the
nameplate and simple nameplate of the inverter.
Figure 3-5 Type designation key
Field
Sign
Description
Contents
Abbreviation
of product
series
①
Abbreviation of
product series
HD2: HD2 series inverter
Rated power
②
Power range +
load type
4.5A = 4.5Amps continuous rating
Voltage class
③
Voltage class
23: AC 3PH 200V (-15%) ~240V (+10%)
43: AC 3PH 380V (-15%) ~440V (+10%)
3.6 Ratings of a single inverter
Table 3–1 AC 3PH 380V (-15%)–440V (+10%)
Product model
Output power (kW)
Input current (A)
Output current (A)
HD2-3.7A-43
1.5
5.0
3.7
HD2-5A-43
2.2
5.8
5
HD2-9.5A-43
4
13.5
9.5
HD2-14A-43
5.5
19.5
14
HD2-18.5A-43
7.5
25
18.5
HD2-25A-43
11
32
25
HD2-32A-43
15
40
32
HD2-38A-43
18.5
47
38
HD2-45A-43
22
51
45
HD2-60A-43
30
70
60
HD2-75A-43
37
80
75
HD2-92A-43
45
98
92
HD2-115A-43
55
128
115
