HD2 Series Inverter Function Parameter List
-236-
Function
code
Name
Description
Default
value
Modify
P19.08
Reserved
0.000–65535
0
●
P19.09
AI3 input voltage
of expansion I/O
card
0.00–10.00V
0.00V
●
P19.10
EC PT100
detected
temperature
-50.0–150.0°C 0.0
●
P19.11
EC PT100
detected digital
0–4096 0
●
P19.12
EC PT1000
detected
temperature
-50.0–150.0°C 0.0 ●
P19.13
EC PT1000
detected digital
0–4096 0 ●
P19.14
Alarm display
0–4
0: No alarm
1: PT100 detected OH alarm (A-Ot1)
2: PT1000 detected OH alarm (A-Ot2)
3: PT100 disconnection alarm (A-Pt1)
4: PT1000 disconnection alarm (A-Pt2)
0
●
P19.15
Inverter control
word
0–65535 0
●
P19.16
Inverter status
word
0–65535 0 ●
P19.17
Ethernet
monitoring
variable 1
0–65535 0 ●
P19.18
Ethernet
monitoring
variable 2
0–65535 0 ●
P19.19
Ethernet
monitoring
variable 3
0–65535 0
●
P19.20
Ethernet
monitoring
variable 4
0–65535 0
●
P19.21
AI/AO detected
temperature
-20.0–200.0°C 0.0 ●
P19.22–
P19.39
Reserved
0–65535
0
●
P20––Encoder of motor 1
Function
code
Name
Description
Default
value
Modify
P20.00
Encoder type
0: Incremental encoder
0
●
