IMO HD2-3.7A-43 - P08-Enhanced Functions

HD2 Series Inverter Function Parameter List
-183-
Function
code
Name
Description
Default
value
Modify
P07.52
Output current at
2nd-last fault
0.0–6300.0A
0.0A
●
P07.53
Bus voltage at
2nd-last fault
0.0–2000.0V
0.0V
●
P07.54
Max. temperature
at 2nd-last fault
-20.0–120.0°C
0.0°C
●
P07.55
Input terminal
status at 2nd-last
fault
0x0000–0xFFFF
0x0000
●
P07.56
Output terminal
status at 2nd-last
fault
0x0000–0xFFFF
0x0000
●
P08––Enhanced functions
Function
code
Name
Description
Default
value
Modify
P08.00
Acceleration
time 2
See P00.11 and P00.12 for detailed definitions.
HD2 series inverter defines four groups of
acceleration/deceleration time, which can be
selected by multi-function digital input terminal
(P05 group). The acceleration/deceleration time of
the inverter is the first group by default.
Setting range: 0.0–3600.0s
Depends
on model
○
P08.01
Deceleration
time 2
Depends
on model
○
P08.02
Acceleration
time 3
Depends
on model
○
P08.03
Deceleration
time 3
Depends
on model
○
P08.04
Acceleration
time 4
Depends
on model
○
P08.05
Deceleration
time 4
Depends
on model
○
P08.06
Running
frequency of
jogging
This function code is used to define the reference
frequency of the inverter during jogging.
Setting range: 0.00Hz–P00.03 (Max. output
frequency)
5.00Hz
○
P08.07
Acceleration time
of jogging
Jogging acceleration time is the time needed for
the inverter to accelerate from 0Hz to Max. output
frequency (P00.03).
Jogging deceleration time is the time needed from
decelerating from Max. output frequency (P00.03)
to 0Hz.
Setting range: 0.0–3600.0s
Depends
on model
○
P08.08
Deceleration time
of jogging
○
