HD2 Series Inverter Basic Operation Guidelines
-85-
Function
code
Name
Description
Default
value
2: Invalid for multi-step speed when
multi-step speed takes priority
Hundreds: Action selection at stop
0: Valid
1: Valid during running, clear after stop
2: Valid during running, clear after
receiving stop command
P08.45
UP terminal frequency
incremental change rate
0.01–50.00 Hz/s
0.50 Hz/s
P08.46
DOWN terminal frequency
decremental change rate
0.01–50.00 Hz/s
0.50 Hz/s
P17.00
Set frequency
0.00Hz–P00.03 (Max. output frequency)
0.00Hz
P17.02
Ramp reference frequency
0.00Hz–P00.03 (Max. output frequency)
0.00Hz
P17.14
Digital adjustment value
0.00Hz–P00.03
0.00Hz
5.5.9 Analog input
The inverter carries two analog input terminals (AI1 is 0–10V/0–20mA (voltage input or current input
can be set by P05.50); AI2 is -10–10V) and two high-speed pulse input terminals. Each input can be
filtered separately, and the corresponding reference curve can be set by adjusting the reference
corresponds to the max. value and min. value.
