HD2 Series Inverter Basic Operation Guidelines
-84-
Function
code
Name
Description
Default
value
7: PID control
8: Modbus/Modbus TCP communication
9: PROFIBUS/CANopen/DeviceNet
communication
10: Ethernet communication
11: High speed pulse HDIB
12: Pulse string AB
13: EtherCAT/PROFINET/EtherNet IP
communication
14: Programmable card
15: Reserved
P00.08
Reference object of B
frequency command
0: Max. output frequency
1: A frequency command
0
P00.09
Combination mode of setup
source
0: A
1: B
2: (A+B)
3: (A-B)
4: Max (A, B)
5: Min (A, B)
0
P05.01–
P05.06
Function of multi-function
digital input terminal (S1–S4,
HDIA, HDIB)
10: Frequency increase (UP)
11: Frequency decrease (DOWN)
12: Clear frequency increase/decrease
setting
13: Switchover between setup A and
setup B
14: Switchover between combination
setup and setup A
15: Switchover between combination
setup and setup B
/
P08.42
Reserved
/
/
P08.43
Reserved
/
/
P08.44
UP/DOWN terminal control
0x000–0x221
Ones: Frequency enabling selection
0: UP/DOWN terminal setting is valid
1: UP/DOWN terminal setting is invalid
Tens: Frequency control selection
0: Valid only when P00.06=0 or P00.07=0
1: Valid for all frequency modes
0x000
