HD2 Series Inverter Function Parameter List
-191-
Function
code
Name
Description
Default
value
Modify
P08.58
Interval of carrier
frequency
reduction
0–30min
10
○
P08.59
AI1
disconnection
detection
threshold
0–100%
0
○
P08.60
AI2
disconnection
detection
threshold
0–100%
0
○
P08.61
AI3
disconnection
detection
threshold
0–100%
0
○
P08.62
Output current
filter time
0.000–10.000s
0.000
○
P08.63
Output torque
filter times
0–8
8
○
P09––PID control
Function
code
Name
Description
Default
value
Modify
P09.00
PID reference
source
When frequency command (P00.06, P00. 07) is
set to 7, or voltage setting channel (P04.27) is set
to 6, the inverter running mode is process PID
control.
This parameter determines the target reference
channel of process PID.
0: Set by P09.01
1: AI1
2: AI2
3: AI3
4: High-speed pulse HDIA
5: Multi-step
6: Modbus/Modbus TCP communication
7: PROFIBUS/CANopen/DeviceNet
communication
8: Ethernet communication
9: High-speed pulse HDIB
10: EtherCAT/PROFINET/EtherNet IP
communication
11: Programmable card
12: Reserved
The set target of process PID is a relative value,
0
○
