HD2 Series Inverter Function Parameter List
-192-
Function
code
Name
Description
Default
value
Modify
for which 100% equals 100% of the feedback
signal of the controlled system.
The system always calculates a relative value (0–
100.0%).
P09.01
PID digital setting
This parameter is mandatory when P09.00 is set to
0. The reference value of this parameter is the
feedback of the system.
Setting range: -100.0%–100.0%
0.0%
○
P09.02
PID feedback
source
This parameter is used to select PID feedback
channel.
0: AI1
1: AI2
2: AI3
3: High-speed pulse HDIA
4: Modbus/Modbus TCP communication
5: PROFIBUS/CANopen/DeviceNet
communication
6: Ethernet communication
7: High-speed pulse HDIB
8: EtherCAT/PROFINET/EtherNet IP
communication
9: Programmable expansion card
10: Reserved
Note: The reference channel and feedback
channel cannot be duplicate. Otherwise, effective
PID control cannot be achieved.
0
○
P09.03
PID output
characteristics
0: PID output is positive characteristic: namely, the
feedback signal is larger than the PID reference,
which requires the inverter output frequency to
decrease for PID to reach balance, eg, tension PID
control of winding
1: PID output is negative characteristics: namely
the feedback signal is less than PID reference,
which requires inverter output frequency to
increase for PID to reach balance, eg, tension PID
control of unwinding.
0
○
P09.04
Proportional gain
(Kp)
This function code is suitable for proportional gain
P of PID input.
It determines the regulation intensity of the whole
1.80
○
