IMO HD2-3.7A-43 - Page 214

HD2 Series Inverter Function Parameter List
-205-
Function
code
Name
Description
Default
value
Modify
group 9 Group 2: Faults 15–18 (OH1, OH2, EF, CE)
Group 3: Faults 19–22 (ItE, tE, EEP, PIDE)
Group 4: Faults 23–26 (bCE, END, OL3, PCE)
Group 5: Faults 27–30 (UPE, DNE, E-DP, E-NET)
Group 6: Faults 31–34 (E-CAN, ETH1, ETH2,
dEu)
Group 7: Faults 35–38 (STo, LL, ENC1O, ENC1D)
Group 8: Faults 39–42 (ENC1Z, STO, STL1,
STL2)
Group 9: Faults 43–46 (STL3, CrCE, P-E1, P-E2)
Group 10: Faults 47–50 (P-E3, P-E4, P-E5, P-E6)
Group 11: Faults 51–54 (P-E7, P-E8, P-E9, P-E10)
Group 12: Faults 55–58 (E-Err, ENCU, E-PN,
SECAN)
Group 13: Faults 59–62 (OT, F1-Er, F2-Er, F3-Er)
Group 14: Faults 63–66 (C1-Er, C2-Er, C3-Er,
E-CAT)
Group 15: Faults 67–70 (E-BAC, E-DEV, S-Err,
OtE1)
Group 16: Faults 71–75 (OtE2, E-EIP, E-PAO,
E-AI1)
Group 17: Faults 75–78 (E-AI2, E-AI3, Reserved,
Reserved)
Group 18: Faults 79–82 (Reserved, Reserved,
Reserved, Reserved)
Group 19: Faults 83–86 (Reserved, Reserved,
Reserved, Reserved)
Group 20: Faults 87–90 (Reserved, Reserved,
Reserved, Reserved)
P11.40
Fault severity
group 10
0x0000 ○
P11.41
Fault severity
group 11
0x0000 ○
P11.42
Fault severity
group 12
0x0000 ○
P11.43
Fault severity
group 13
0x0000
○
P11.44
Fault severity
group 14
0x0000
○
P11.45
Fault severity
group 15
0x0000
○
P11.46
Fault severity
group 16
0x0000
○
P11.47
Fault severity
group 17
0x0000
○
P11.48
Fault severity
group 18
0x0000 ○
P11.49
Fault severity
group 19
0x0000 ○
P11.50
Fault severity
group 20
0x0000
○
P11.51
Action for fault
pre-alarm
0–4
0: Run at the set frequency
1: Run at the output frequency at the time of fault
2: Run at the frequency upper limit
3: Run at the frequency lower limit
4: Run at the frequency reserved for exception
0
○
P11.52
Frequency
reserved for
exception
0.00–630.00(Hz)
0.00
○
P11.53
Fire mode
function
0–2
0: Invalid
1: Fire mode 1
2: Fire mode 2
When P11.53=0, the fire mode is invalid, and the
normal running mode is used. In this case, the
inverter stops when encountering a fault.
When the fire mode function is valid, the inverter
runs at the speed specified by P11.54.
When fire mode 1 is selected, the inverter always
0
◎
