HD2 Series Inverter Basic Operation Guidelines
-55-
Function
code
Name
Description
Default
value
4: AI3
5: Pulse frequency HDIA
6: Multi-step torque
7: Modbus/Modbus TCP communication
8: PROFIBUS/CANopen/DeviceNet
communication
9: Ethernet communication
10: Pulse frequency HDIB
11: EtherCAT/PROFINET/EtherNet IP
communication
12: Programmable card
Note: For these settings, 100%
corresponds to the motor rated current.
P03.12
Torque set through keypad
-300.0%–300.0% (of the motor rated
current)
50.0%
P03.13
Torque reference filter time
0.000–10.000s
0.010s
P03.14
Setting source of FWD
rotation frequency upper
limit in torque control
0: Keypad (P03.16)
1: AI1
2: AI2
3: AI3
4: Pulse frequency HDIA
5: Multi-step setting
6: Modbus/Modbus TCP communication
7: PROFIBUS/CANopen/DeviceNet
communication
8: Ethernet communication
9: Pulse frequency HDIB
10: EtherCAT/PROFINET/EtherNet IP
communication
11: Programmable card
12: Reserved
Note: For these settings, 100%
corresponds to the max. frequency.
0
P03.15
Setting source of REV
rotation frequency upper
limit in torque control
0: Keypad (P03.17)
1–11: Same as those of P03.14
0
P03.16
FWD rotation frequency
upper limit set through
keypad in torque control
Value range: 0.00 Hz–P00.03 (Max. output
frequency)
50.00Hz
