HD2 Series Inverter Function Parameter List
-228-
Function
code
Name
Description
Default
value
Modify
frequency
open-loop vector condition.
Range: 0.00– P00.03
P17.11
DC bus voltage
Display current DC bus voltage of the inverter.
Range: 0.0–2000.0V
0V
●
P17.12
Digital input
terminal state
Display current digital input terminal state of the
inverter.
0000–03F
Corresponds to HDIB, HDIA, S4, S3, S2 and S1
respectively
0
●
P17.13
Digital output
terminal state
Display current digital output terminal state of the
inverter.
0000–000F
Corresponds to RO2, RO1, HDO and Y1
respectively
0
●
P17.14
Digital
adjustment
variable
Display the regulating variable by UP/DOWN
terminals of the inverter.
Range: 0.00Hz–P00.03
0.00Hz
●
P17.15
Torque reference
value
Relative to percentage of the rated torque of
current motor, display torque reference.
Range: -300.0%–300.0% (of the motor rated
current)
0.0%
●
P17.16
Linear speed
0–65535
0
●
P17.17
Reserved
0–65535
0
●
P17.18
Count value
0–65535
0
●
P17.19
AI1 input voltage
Display input signal of AI 1
Range: 0.00–10.00V
0.00V
●
P17.20
AI2 input voltage
Display input signal of AI2
Range: -10.00V–10.00V
0.00V
●
P17.21
HDIA input
frequency
Display input frequency of HDIA
Range: 0.000–50.000kHz
0.000
kHz
●
P17.22
HDIB input
frequency
Display input frequency of HDIB
Range: 0.000–50.000kHz
0.000
kHz
●
P17.23
PID reference
value
Display PID reference value
Range: -100.0–100.0%
0.0%
●
P17.24
PID feedback
value
Display PID feedback value
Range: -100.0–100.0%
0.0%
●
P17.25
Motor power
factor
Display the power factor of current motor.
Range: -1.00–1.00
1.00
●
