HD2 Series Inverter Expansion Cards
-329-
 applicable to sheet metal
machines.
WIFI communication card
HD2-E-WFP
HD2-E-WFM
 Meeting IEEE802.11b/g/n
 With IMO's mobile phone APP, you
can monitor the inverter locally or
remotely through WIFI
communication
 The maximum communication distance
in open environments is 30 m.
 HD2-E-WFP is equipped with
a built-in antenna and
applicable to molded case
machines.
 HD2-E-WFM is configured with an
external sucker antenna and
 applicable to sheet metal
machines.
Ethernet communication
card
HD2-E-ENET
 Supporting Ethernet communication
with IMO's internal protocol
 Can be used in combination with
IMO's upper computer
monitoring software Drive Studio
CANopen
communication
card
HD2-E-COP
 Based on the CAN2.0A physical layer
 Supporting the CANopen
protocol
CAN master/slave control
communication card
HD2-E-CAN
 Based on the CAN2.0B physical layer
 Adopting IMO's master-slave
control proprietary protocol
Profibus-DP
communication card
HD2-E-PDP
 Supporting the Profibus-DP
protocol
PROFINET
communication
card
HD2-E-PRF
 Supporting the PROFINET
protocol
Multi-function
incremental PG card
HD2-E-PGIM
 Applicable to OC encoders of 5 V or 12
V
 Applicable to push-pull encoders of 5 V
or 12 V
 Applicable to differential encoders of 5
V
 Supporting the orthogonal input of A, B,
and Z
 Supporting the frequency-divided
output of A, B, and Z
 Supporting pulse string setting
24V incremental PG card
HD2-E-PGIM24
 Applicable to 24V OC encoders
 Applicable to 24 V push-pull encoders
 Applicable to 5 V differential encoders
 Supporting A, B, Z orthogonal input
 Supporting A, B, Z frequency-divided
