HD2 Series Inverter Expansion Cards
-330-
output
 Supporting pulse string
reference input
UVW incremental PG
card
HD2-E-PGI
 Applicable to differential encoders of 5
V
 Supporting the orthogonal input
of A, B, and Z
 Supporting pulse input of phase U, V,
and W
 Supporting the frequency-divided
output of A, B, and Z
 Supporting the input of pulse
string reference
Resolver PG card
HD2-E-PGR
 Applicable to resolver encoders
 Supporting frequency-divided
output of resolver-simulated A,
B, Z
Sin/Cos PG card
HD2-E-PGISC
 Applicable to Sin/Cos encoders with or
without CD signals
 Supporting A, B, Z frequency-divided
output
 Supporting pulse string
reference input
Remarks: Contact us for details about the EtherCAT communication card, 24V power supply card,
and the shockproof GPRS card with high-precision GPS positioning.
IO expansion card
HD2-E-IO
IO expansion card 2
HD2-E-IO2
