HD2 Series Inverter Function Parameter List
-210-
Function
code
Name
Description
Default
value
Modify
Setting range: 0.0%–100.0% (of the motor rated
current)
P13.01
Initial pole
detection mode
0: No detection
1: High-frequency current injection
2: Pulse superimposition
0
◎
P13.02
Injection current
1
Injection current is the pole position orientation
current; injection current 1 is valid within the lower
limit of injection current switchover frequency
threshold. If you need to increase the starting
torque, increase the value of this function code
properly.
Setting range: 0.0%–100.0% (of the motor rated
current)
20.0%
○
P13.03
Injection current
2
Injection current is the pole position orientation
current; injection current 2 is valid within the upper
limit of injection current switchover frequency
threshold, and you do not need to change injection
current 2 under common situations.
Setting range: 0.0%–100.0% (of the motor rated
current)
10.0%
○
P13.04
Injection current
switchover
frequency
0.00Hz–200.0% (of the motor rated current)
20.0%
○
P13.05
High-frequency
superposition
frequency
(reserved)
200Hz–1000Hz
500Hz
◎
P13.06
Pulse current
setting
This parameter is used to set the pulse current
threshold when the initial magnetic pole position is
detected in the pulse mode. The value is a
percentage in relative to the rated current of the
motor.
Setting range: 0.0–300.0% (of the rated voltage of
the motor)
100.0%
◎
P13.07
Reserved
0.0–400.0
0.0
○
P13.08
Control
parameter 1
0–0xFFFF
0
○
P13.09
Frequency
This parameter is used to set the frequency
50.00
○
