HD2 Series Inverter Function Parameter List
-231-
Function
code
Name
Description
Default
value
Modify
torque
P17.47
Motor pole pairs
0–65535
0
●
P17.48
inverter overload
count value
0–65535
0
●
P17.49
Frequency set by
A source
0.00–P00.03
0.00Hz
●
P17.50
Frequency set by
B source
0.00–P00.03
0.00Hz
●
P17.51
PID proportional
output
-100.0%–100.0%
0.00%
●
P17.52
PID integral
output
-100.0%–100.0%
0.00%
●
P17.53
PID differential
output
-100.0%–100.0%
0.00%
●
P17.54
Actual PID
proportional gain
0.00–100
0.00%
●
P17.55
Actual PID
integral time
0.00–10.00s
0.00%
●
P17.56
Actual PID
differential time
0.00–10.00s
0.00%
●
P17.57
Peak value at
100Hz frequency
component
(square-wave
orthogonal
function
detected)
0.0–300.0V
Peak value of bus voltage fluctuation at 100Hz
frequency component, which is detected by using
a square-wave orthogonal function
0.0V
●
P17.58
Peak value at
100Hz frequency
component
(sine-wave
orthogonal
function
detected)
0.0–300.0V
Peak value of bus voltage fluctuation at 100Hz
frequency component, which is detected by using
a sine-wave orthogonal function
0.0V
●
P17.59–
P17.63
Reserved
0–65535
0
●
