HD2 Series Inverter Function Parameter List
-248-
Function
code
Name
Description
Default
value
Modify
P22.06
Spindle zeroing
position 3
Setting range: 0–65535
0
○
P22.07
Spindle
scale-division
angle 1
You can select seven spindle scale-division values
by terminals (functions 48, 49 and 50).
Setting range: 0.00–359.99
15.00
○
P22.08
Spindle
scale-division
angle 2
Setting range: 0.00–359.99
30.00
○
P22.09
Spindle
scale-division
angle 3
Setting range: 0.00–359.99
45.00
○
P22.10
Spindle
scale-division
angle 4
Setting range: 0.00–359.99
60.00
○
P22.11
Spindle
scale-division
angle 5
Setting range: 0.00–359.99
90.00
○
P22.12
Spindle
scale-division
angle 6
Setting range: 0.00–359.99
120.00
○
P22.13
Spindle
scale-division
angle 7
Setting range: 0.00–359.99
180.00
○
P22.14
Spindle drive
ratio
This parameter specifies the reduction ratio of the
spindle and the mounting shaft of the encoder.
Setting range: 0.000–30.000
1.000
○
P22.15
Zero-point
communication
setup of spindle
P22.15 sets spindle zero-point offset, if the
selected spindle zero point is P22.03, the final
spindle zero point will be the sum of P22.03 and
P22.15.
Setting range: 0–39999
0
○
P22.16
Reserved
0–65535
0
○
P22.17
Reserved
0–65535
0
○
P22.18
Rigid tapping
selection
Ones: Enable/disable
0: Disable
1: Enable
Tens: Analog port selection
0: Invalid
0x00
◎
